D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1032
<ipv6addr> | <domain_name 255>] dest_file <path_filename 64> {unit <unit_id>} |
firmware_toTFTP [<ipaddr> | <ipv6addr> | <domain_name 255>] dest_file <path_filename
64> {unit <unit_id>} {src_file <pathname>}]
Parameters
cfg_toTFTP – Specify that the configuration file will be uploaded to the TFTP server.
<ipaddr> - The IP address of the TFTP server.
<ipv6addr> - The IPv6 address of the TFTP server.
<domain_name 255> - Enter the domain name of the TFTP server.
dest_file - Used to identify the parameter “path_filename”.
<path_filename 64> - The pathname specifies the pathname on the TFTP server. It can
be a relative pathname or an absolute pathname. This name can be up to 64 characters
long.
unit - (Optional) Specify which unit on the stacking system. If it is not specified, it refers to the
master unit.
<unit_id> - Enter the unit ID value. This value must be between 1 and 6.
src_file - (Optional) Used to identify the parameter “path_filename”.
<pathname> - The pathname specifies an absolute pathname on the device file system. If
pathname is not specified, it refers to the boot_up CFG file.
include - (Optional) Specify to include lines that contain the specified filter string.
exclude - (Optional) Specify to exclude lines that contain the specified filter string.
begin - (Optional) The first line that contains the specified filter string will be the first line of the
output.
<filter_string 80> - A filter string is enclosed by symbol. Thus, the filter string itself cannot
contain the character. The filter string is case sensitive. This string can be up to 80
characters long.
<filter_string 80> - (Optional) A filter string is enclosed by symbol. Thus, the filter string itself
cannot contain the character. The filter string is case sensitive. This string can be up to 80
characters long.
<filter_string 80> - (Optional) A filter string is enclosed by symbol. Thus, the filter string
itself cannot contain the character. The filter string is case sensitive. This string can be
up to 80 characters long.
include - (Optional) Specify to include lines that contain the specified filter string.
exclude - (Optional) Specify to exclude lines that contain the specified filter string.
begin - (Optional) The first line that contains the specified filter string will be the first line of the
output.
<filter_string 80> - A filter string is enclosed by symbol. Thus, the filter string itself cannot
contain the character. The filter string is case sensitive. This string can be up to 80
characters long.
<filter_string 80> - (Optional) A filter string is enclosed by symbol. Thus, the filter string itself
cannot contain the character. The filter string is case sensitive. This string can be up to 80
characters long.
<filter_string 80> - (Optional) A filter string is enclosed by symbol. Thus, the filter string
itself cannot contain the character. The filter string is case sensitive. This string can be
up to 80 characters long.
include - (Optional) Specify to include lines that contain the specified filter string.
exclude - (Optional) Specify to exclude lines that contain the specified filter string.
begin - (Optional) The first line that contains the specified filter string will be the first line of the
output.
<filter_string 80> - A filter string is enclosed by symbol. Thus, the filter string itself cannot
contain the character. The filter string is case sensitive. This string can be up to 80
characters long.
<filter_string 80> - (Optional) A filter string is enclosed by symbol. Thus, the filter string itself
cannot contain the character. The filter string is case sensitive. This string can be up to 80
characters long.
<filter_string 80> - (Optional) A filter string is enclosed by symbol. Thus, the filter string
itself cannot contain the character. The filter string is case sensitive. This string can be

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
