xStack

DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide

1057

Restrictions

None.

Example

To display trusted host:

DGS-3120-24TC:admin#show trusted_host

Command: show trusted_host

Management Stations

IP Address Access Interface

----------------------------------------------------------------

10.48.74.121 SNMP Telnet SSH HTTP HTTPs Ping

Total Entries: 1

DGS-3120-24TC:admin#
