D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1111
DGS-3120-24TC:admin#config wred profile profile_id 2 min_threshold 30
max_threshold 50 max_drop_rate 10
Command: config wred profile profile_id 2 min_threshold 30 max_threshold 50
max_drop_rate 10
Success.
DGS-3120-24TC:admin#
121-5 config wred ports
Description
This command is used to configure the WRED parameters of the ports.
Format
config wred ports [<portlist> | all] [cos <class_id 0-7> [profile [default | profile_id <int 2-128>
| <profile_name 32>] | weight <int 0-15>] | profile [default | profile_id <int 2-128> |
<profile_name 32>] | weight <int 0-15>]
Parameters
<portlist> - Specify a range of ports to be configured.
all - Specify all ports to be configured.
cos – Specify the hardware priority queues.
<class_id 0-7> - Enter the priority between 0 and 7.
profile - Specify the profile to be used.
default - Specify the default profile to be used.
profile_id - Specify the profile ID to be used.
<int 2-128> - Enter the profile ID between 2 and 128.
<profile_name 32> - Specify the profile name to be used.
weight – Specify the weight of average queue size formular.
<int 0-15> - Enter the weight between 0 and 15.
profile - Specify the profile to be used.
default - Specify the default profile to be used.
profile_id - Specify the profile ID to be used.
<int 2-128> - Enter the profile ID between 2 and 128.
<profile_name 32> - Specify the profile name to be used.
weight – Specify the weight of average queue size formular.
<int 0-15> - Enter the weight between 0 and 15.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the port 1:1 as queue 2 and to use the profile 2:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
