D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1114
Parameters
default - (Optional) Specify the default profile to be displayed.
profile_id - (Optional) Specify the profile ID to be displayed.
<int 2-128> - Enter the profile ID between 2 and 128.
<profile_name 32> - (Optional) Specify the profile name to be displayed.
Restrictions
None.
Example
To display the WRED profile information:
DGS-3120-24TC:admin#show wred profile
Command: show wred profile
Total Profile Number: 2
WRED Profile ID: 1 Profile Name: default
Packet Type Min-Threshold Max-Threshold Max-Drop-Rate
--------------- ------------- ------------- -------------
TCP-GREEN 50 100 50
TCP-YELLOW 50 100 50
TCP-RED 50 100 50
NON-TCP-GREEN 50 100 50
NON-TCP-YELLOW 50 100 50
NON-TCP-RED 50 100 50
WRED Profile ID: 2 Profile Name: profilename
Packet Type Min-Threshold Max-Threshold Max-Drop-Rate
--------------- ------------- ------------- -------------
TCP-GREEN 50 100 50
TCP-YELLOW 50 100 50
TCP-RED 50 100 50
NON-TCP-GREEN 50 100 50
NON-TCP-YELLOW 50 100 50
NON-TCP-RED 50 100 50
DGS-3120-24TC:admin#

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
