D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
124
7-1 create egress_access_profile profile_id
Description
This command is used to create an egress access list profile. For example, for some hardware, it
may be invalid to specify destination IPv6 address and source IPv6 address at the same time. The
user will be prompted for these limitations.
Format
create egress_access_profile profile_id <value 1-4> profile_name <name 1-32> [ethernet
{vlan {<hex 0x0-0x0fff>} | source_mac <macmask 000000000000-ffffffffffff> |
destination_mac <macmask 000000000000-ffffffffffff> | 802.1p | ethernet_type} | ip {vlan
{<hex 0x0-0x0fff>} | source_ip_mask <netmask> | destination_ip_mask <netmask> | dscp |
[icmp {type | code} | igmp {type} | tcp {src_port_mask <hex 0x0-0xffff> | dst_port_mask
<hex 0x0-0xffff> | flag_mask [all | {urg | ack | psh | rst | syn | fin}]} | udp {src_port_mask
<hex 0x0-0xffff> | dst_port_mask <hex 0x0-0xffff>} | protocol_id_mask <hex 0x0-0xff>
{user_define_mask <hex 0x0-0xffffffff>}]} | ipv6 {class | source_ipv6_mask <ipv6mask> |
destination_ipv6_mask <ipv6mask> | [tcp {src_port_mask <hex 0x0-0xffff> | dst_port_mask
<hex 0x0-0xffff>} | udp {src_port_mask <hex 0x0-0xffff> | dst_port_mask <hex 0x0-0xffff>} |
icmp {type | code}]}]
Parameters
profile_id - Specify the index of the egress access list profile.
<value 1-4> - Enter the profile ID used here. This value must be between 1 and 4. A lower
value denotes a higher priority.
profile_name - The name of the profile must be specified. The maximum length is 32 characters.
<name 1-32> - Enter the profile name used here. This name can be up to 32 characters long.
ethernet - Specify this is an Ethernet mask.
vlan - (Optional) Specify a VLAN mask.
<hex 0x0-0x0fff> - Enter the VLAN mask used here.
source_mac - (Optional) Specify the source MAC mask.
<macmask> - Enter the source MAC mask used here.
destination_mac - (Optional) Specify the destination MAC mask.
<macmask> - Enter the destination MAC mask used here.
802.1p - (Optional) Specify 802.1p priority tag mask.
ethernet_type - (Optional) Specify the Ethernet type mask.
ip - Specify this is an IPv4 mask.
vlan - (Optional) Specify a VLAN mask.
<hex 0x0-0x0fff> - Enter the VLAN mask used here.
source_ip_mask - (Optional) Specify a source IP address mask.
<netmask> - Enter the source network mask used here.
destination_ip_mask - (Optional) Specify a destination IP address mask.
<netmask> - Enter the destination network mask used here.
dscp - (Optional) Specify the DSCP mask.
icmp - (Optional) Specify that the rule applies to ICMP traffic.
type - Specify the type of ICMP traffic.
code - Specify the code of ICMP traffic.
igmp - (Optional) Specify that the rule applies to IGMP traffic.
type - Specify the type of IGMP traffic.
tcp - (Optional) Specify that the rule applies to TCP traffic.
src_port_mask - Specify the TCP source port mask.
<hex 0x0-0xffff> - Enter the TCP source port mask value here.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
