xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
127
<value 0-255> | source_ipv6 <ipv6addr> {mask <ipv6mask>} | destination_ipv6 <ipv6addr>
{mask <ipv6mask>} | [tcp {src_port <value 0-65535> {mask <hex 0x0-0xffff>} | dst_port
<value 0-65535> {mask <hex 0x0-0xffff>}} | udp {src_port <value 0-65535> {mask <hex 0x0-
0xffff>} | dst_port <value 0-65535> {mask <hex 0x0-0xffff>}} | icmp {type <value 0-255> |
code <value 0-255>} ]}] [vlan_based [vlan <vlan_name 32> | vlan_id <vlanid 1-4094>] |
port_group [id<value 1-64> | name <name 16>] | port <port>] [permit {replace_priority_with
<value 0-7> | replace_dscp_with <value 0-63> | counter[enable | disable]} | deny]
{time_range <range_name 32>} | delete access_id <value 1-128>]
Parameters
profile_id - Specify the index of the egress access list profile.
<value 1-4> - Enter the profile ID used here. This value must be between 1 and 4. A lower
value denotes a higher priority.
profile_name - Specify the name of the profile.
<name 1-32> - Enter the profile name here. This name can be up to 32 characters long.
add - Specify to add a profile or rule.
access_id - Specify the index of the access list entry. If the auto_assign option is selected, the
access ID is automatically assigned.
auto assign - Specify that the access ID will be configured automatically.
<value 1-128> - Enter the access ID used here. This value must be between 1 and 128.
ethernet - Specify an Ethernet egress ACL rule.
vlan - (Optional) Specify the VLAN name.
<vlan_name 32> - Enter the VLAN name used for this configuration here. This name can be
up to 32 characters long.
vlanid - Specify a VLAN ID.
<vlanid 1-4094> - Enter the VLAN ID used for this congfiguration here. This value must be
between 1 and 4094.
source_mac - (Optional) Specify the source MAC address.
<macaddr> - Enter the source MAC address used here.
mask - Specify that source MAC mask used.
<macmask> - Enter the source MAC mask value here.
destination_mac - Specify the destination MAC address.
<macaddr> - Enter the destination MAC address used here.
mask - Specify that destination MAC mask used.
<macmask> - Enter the destination MAC mask value here.
802.1p - (Optional) Specify the value of the 802.1p priority tag. The priority tag ranges from 1 to
7.
<value 0-7> - Enter the 802.1p priority tag used here.
ethernet_type - (Optional) Specify the Ethernet type.
<hex 0x0-0xffff> - Enter the Ethernet type mask used here.
ip - Specify an IP egress ACL rule.
vlan - (Optional) Specify the VLAN name.
<vlan_name 32> - Enter the VLAN name used for this configuration here. This name can be
up to 32 characters long.
vlanid - Specify a VLAN ID.
<vlanid 1-4094> - Enter the VLAN ID used for this congfiguration here. This value must be
between 1 and 4094.
mask - (Optional) Specify the mask used.
<hex 0x0-x0fff> - Enter the mask value used here.
source_ip - (Optional) Specify an IP source address.
<ipaddr> - Enter the source IP address used here.
mask - Specify the source IP address used here.
<netmask> - Enter the source network mask here.
destination_ip - (Optional) Specify an IP destination address.
<ipaddr> - Enter the destination IP address used here.
mask - Specify the destination IP address used here.
