xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
128
<netmask> - Enter the destination network mask here.
dscp - (Optional) Specify the value of DSCP. The DSCP value ranges from 0 to 63.
<value 0-63> - Enter the DSCP value used here. This value must be between 0 and 63.
icmp - (Optional) Specify that the following parameters configured will apply to the ICMP
configuration.
type - Specify that the rule will apply to the ICMP type traffic value.
<value 0-255> - Enter the ICMP traffic type value here. This value must be between 0 and
255.
code - Specify that the rule will apply to the ICMP code traffic value.
<value 0-255> - Enter the ICMP code traffic value here. This value must be between 0 and
255.
igmp - (Optional) Specify that the following parameters configured will apply to the IGMP
configuration.
type - Specify that the rule will apply to the IGMP type traffic value.
<value 0-255> - Enter the IGMP type traffic value here. This value must be between 0 and
255.
tcp - (Optional) Specify that the following parameters configured will apply to the TCP
configuration.
src_port - Specify that the rule will apply to a range of TCP source ports.
<value 0-65535> - Enter the source port value here. This value must be between 0 and
65535.
mask - Specify the TCP source port mask here.
<hex 0x0-0xffff> - Enter the TCP source port mask value here.
dst_port - Specify that the rule will apply to a range of TCP destination ports.
<value 0-65535> - Enter the destination port value here. This value must be between 0
and 65535.
mask - Specify the TCP destination port mask here.
<hex 0x0-0xffff> - Enter the TCP destination port mask value here.
flag - (Optional) Specify the TCP flag fields.
all - Specify that the TCP flag field will be set to 'all'.
urg - Specify that the TCP flag field will be set to 'urg'.
ack - Specify that the TCP flag field will be set to 'ack'.
psh - Specify that the TCP flag field will be set to 'psh'.
rst - Specify that the TCP flag field will be set to 'rst'.
syn - Specify that the TCP flag field will be set to 'syn'.
fin - Specify that the TCP flag field will be set to 'fin'.
udp - (Optional) Specify that the following parameters configured will apply to the UDP
configuration.
src_port - Specify the UDP source port range.
<value 0-65535> - Enter the UDP source port range value here.
mask - Specify the UDP source port mask here.
<hex 0x0-0xffff> - Enter the UDP source port mask value here.
dst_port - Specify the UDP destination port range.
<value 0-65535> - Enter the UDP destination port range value here.
mask - Specify the UDP destination port mask here.
<hex 0x0-0xffff> - Enter the UDP destination port mask value here.
protocod_id - (Optional) Specify that the rule will apply to the value of IP protocol ID traffic.
<value 0-255> - Enter the protocol ID used here. This value must be between 0 and 255.
user_define - (Optional) Specify that the rule will apply to the IP protocol ID and that the mask
options behind the IP header, which has a length of 20 bytes.
<hex 0x0-0xffffffff> - Enter the user-defined mask value here.
mask - Specify the user-defined mask here.
<hex 0x0-0xffffffff> - Enter the user-defined mask value here.
ipv6 - Specify the rule applies to IPv6 fields.
class - (Optional) Specify the value of IPv6 class.
<value 0-255> - Enter the IPv6 class value here. This value must be between 0 and 255.
source_ipv6 - (Optional) Specify the value of IPv6 source address.
<ipv6addr> - Enter the source IPv6 source address here.
mask - Specify the IPv6 source address mask here.
