xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
129
<ipv6mask> - Enter the IPv6 source address mask value here.
destination_ipv6 - (Optional) Specify the value of IPv6 destination address.
<ipv6addr> - Enter the source IPv6 destination address here.
mask - Specify the IPv6 destination address mask here.
<ipv6mask> - Enter the IPv6 destination address mask value here.
tcp - (Optional) Specify the TCP protocol
src_port - Specify the value of the IPv6 layer 4 TCP source port.
<value 0-65535> - Enter the IPv6 TCP source port value here. This value must be
between 0 and 65535.
mask - Specify the IPv6 TCP source port mask here.
<hex 0x0-0xffff> - Enter the IPv6 TCP source port mask value here.
dst_port - Specify the value of the IPv6 layer 4 TCP destination port.
<value 0-65535> - Enter the IPv6 TCP destination port value here. This value must be
between 0 and 65535.
mask - Specify the IPv6 TCP destination port mask here.
<hex 0x0-0xffff> - Enter the IPv6 TCP destination port mask value here.
udp - (Optional) Specify the UDP protocol.
src_port - Specify the value of the IPv6 layer 4 UDP source port.
<value 0-65535> - Enter the IPv6 UDP source port value here. This value must be
between 0 and 65535.
mask - Specify the IPv6 UDP source port mask here.
<hex 0x0-0xffff> - Enter the IPv6 UDP source port mask value here.
dst_port - Specify the value of the IPv6 layer 4 UDP destination port.
<value 0-65535> - Enter the IPv6 UDP destination port value here. This value must be
between 0 and 65535.
mask - Specify the IPv6 UDP destination port mask here.
<hex 0x0-0xffff> - Enter the IPv6 UDP destination port mask value here.
icmp - (Optional) Specify that the following parameters configured will apply to the ICMP
configuration.
type - Specify that the rule will apply to the ICMP type traffic value.
<value 0-255> - Enter the ICMP traffic type value here. This value must be between 0 and
255.
code - Specify that the rule will apply to the ICMP code traffic value.
<value 0-255> - Enter the ICMP code traffic value here. This value must be between 0 and
255.
vlan_based - The rule applies on the specified VLAN.
vlan - Specify the VLAN name.
<vlan_name 32> - Enter the VLAN name used for this configuration here. This name can
be up to 32 characters long.
vlanid - Specify a VLAN ID.
<vlanid 1-4094> - Enter the VLAN ID used for this congfiguration here. This value must be
between 1 and 4094.
port_group - Specify the port group value here.
id - Specify the ID of the port group which the rule applies.
<value 1-64> - Enter the group ID value here. This value must be between 1 and 64.
name - Specify the name of the port group which the rule applies.
<name_string 16> - Enter the port group name here. This name can be up to 16
characters long.
permit - Specify that packets matching the egress access rule are permitted by the Switch.
replace_priority_with - (Optional) Specify the packets that match the egress access rule are
changed the 802.1p priority tag field by the Switch.
<value 0-7> - Enter the replace priority with value here. This value must be between 0 and 7.
replace_dscp_with - (Optional) Specify the packets that match the egress access rule are
changed the DSCP value by the Switch.
<value 0-63> - Enter the replace DSCP with value here. This value must be between 0 and
63.
counter - (Optional) Specify whether the ACL counter feature is enabled or disabled. This
parameter is optional. The default option is disabled. If the rule is not bound with the
flow_meter, all matching packets are counted. If the rule is bound with the flow_meter, then
