D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
135
Parameters
profile_id - Specify the profile ID.
<value 1-4> - Enter the profile ID used here. This value must be between 1 and 4. A lower
value denotes a higher priority.
profile_name - Specify the name of the profile. The maximum length is 32 characters.
<name> - Enter the profile name used here.
access_id - Specify the access ID.
<value 1-128> - Enter the access ID used here. This value must be between 1 and 128. A
lower value denotes a higher priority.
rate - This specifies the rate for single rate two-color mode. Specify the committed bandwidth in
Kbps for the flow. The value m and n are determined by the project.
<value> - Enter the rate for single rate two-color mode here.
burst_size - (Optional) This specifies the burst size for the single rate “two color” mode. The unit
is Kbytes.
<value 0-131072>- Enter the burst size value here.
rate_exceed - This specifies the action for packets that exceed the committed rate in single rate
“two color” mode. The action can be specified as one of the following:
drop_packet - Drop the packet immediately.
remark_dscp - Mark the packet with a specified DSCP. The packet is set to have the higher
drop precedence.
<value 0-63> - Enter the remark DSCP value here. This value must be between 0 and 63.
tr_tcm - Specify the “two rate three color mode”.
cir - Specify the Committed Information Rate in Kbps.
<value 0-1048576> - Enter the value between 0 and 1048576.
cbs - (Optional) Specify the “Committed Burst Size”. The unit is Kbytes. That is to say, 1
means 1Kbytes. This parameter is an optional parameter. The default value is 4*1024.
<value 0-131072> - Enter the comitted burst size value here.
pir - Specify the “Peak Information Rate”. The unit is in Kbps. PIR should always be equal to
or greater than CIR.
<value 0-1048576> - Enter the peak information rate value here.
pbs - (Optional) Specify the “Peak Burst Size”. The unit is in Kbytes.
<value 0-131072> - Enter the peak burst size value here.
color_blind - (Optional) Specify the meter mode to be color-blind. The default is color-blind
mode.
color_aware - (Optional) Specify the meter mode to be color-aware. When this code is
specified, user could set the “in-coming packet color” by using command “config
color_aware”. The final color of packet is determined by the initial color of packet and the
metering result.
conform - (Optional) Specify the action when packet is in “green color”.
permit - Permit the packet.
replace_dscp - Changes the DSCP of the packet.
<value 0-63> - Enter the replace DSCP value here. This value must be between 0 and
63.
counter - (Optional) Specify the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared
when the function is disabled.
enable - Specify that the ACL counter parameter will be enabled.
disable - Specify that the ACL counter parameter will be disabled.
exceed - Specify the action when packet is in “yellow color”.
permit - (Optional) Permit the packet.
replace_dscp - Changes the DSCP of the packet.
<value 0-63> - Enter the DSCP replace value here. This value must be between 0
and 63.
drop - Drops the packet.
counter - (Optional) Specify the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared
when the function is disabled.
enable - Specify that the ACL counter parameter will be enabled.
disable - Specify that the ACL counter parameter will be disabled.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
