D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
136
violate - Specify the action when packet is in “red color”.
permit - Permit the packet.
replace_dscp - (Optional) Changes the DSCP of the packet.
<value 0-63> - Enter the DSCP replace value here. This value must be between 0
and 63.
drop - Drops the packet.
counter - (Optional) Specify the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared
when the function is disabled.
enable - Specify that the ACL counter parameter will be enabled.
disable - Specify that the ACL counter parameter will be disabled.
sr_tcm - Specify the “single rate three color mode”.
cir - Specify the Committed Information Rate in Kbps.
<value 0-1048576> - Enter the single rate three color mode value here.
cbs - Specify the “committed burst size”. The unit is Kbytes.
<value 0-131072> - Enter the committed burst size value here.
ebs - Specify the “Excess Burst Size”. The unit is Kbytes.
<value 0-131072> - Enter the excess burst size value here.
color_blind - (Optional) Specify the meter mode to be color-blind. The default is color-blind
mode.
color_aware - (Optional) Specify the meter mode to be color-aware. When this code is
specified, user could set the “in-coming packet color” by using command “config
color_aware”. The final color of packet is determined by the initial color of packet and the
metering result.
conform - (Optional) Specify the action when packet is in “green color”.
permit - (Optional) Permit the packet.
replace_dscp - Changes the DSCP of the packet.
<value 0-63> - Enter the replace DSCP value here. This value must be between 0 and
63.
counter - (Optional) Specify the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared
when the function is disabled.
enable - Specify that the ACL counter parameter will be enabled.
disable - Specify that the ACL counter parameter will be disabled.
exceed - Specify the action when packet is in “yellow color”.
permit - Permit the packet.
replace_dscp - (Optional) Changes the DSCP of the packet.
<value 0-63> - Enter the DSCP replace value here. This value must be between 0
and 63.
drop - Drops the packet.
counter - (Optional) Specify the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared
when the function is disabled.
enable - Specify that the ACL counter parameter will be enabled.
disable - Specify that the ACL counter parameter will be disabled.
violate - Specify the action when packet is in “red color”.
permit - Permit the packet.
replace_dscp - (Optional) Changes the DSCP of the packet.
<value 0-63> - Enter the DSCP replace value here. This value must be between 0
and 63.
drop - Drops the packet.
counter - (Optional) Specify the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared
when the function is disabled.
enable - Specify that the ACL counter parameter will be enabled.
disable - Specify that the ACL counter parameter will be disabled.
delete - Delete the specified “flow_meter”.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
