xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
237
destination_ip - (Optional) Specify an IP destination address.
<ipaddr> - Enter the destination IP address used for this configuration here.
mask - (Optional) Specify the mask.
<netmask> - Specify the mask.
dscp - (Optional) Specify the value of DSCP, the value can be configured 0 to 63.
<value> - Enter the DSCP value used here.
icmp - (Optional) Specify that the rule applies to ICMP traffic.
type - Specify that the rule applies to the value of ICMP type traffic.
<value 0-255> - Enter the ICMP type value here. This value must be between 0 and 255.
code - Specify that the rule applies to the value of ICMP code traffic.
<value 0-255> - Enter the ICMP code value here. This value must be between 0 and 255.
igmp - (Optional) Specify that the rule applies to IGMP traffic.
type - Specify that the rule applies to the value of IGMP type traffic.
<value 0-255> - Enter the IGMP type value here. This value must be between 0 and 255.
tcp - (Optional) Specify that the rule applies to TCP traffic.
src_port - Specify that the rule applies the range of TCP source port.
<value 0-65535> - Enter the source port value here. This value must be between 0 and
65535.
mask - (Optional) Specify the mask.
<hex 0x0-0xffff> - Specify the mask.
dst_port - Specify the range of TCP destination port range.
<value 0-65535> - Enter the destination port value here. This value must be between 0
and 65535.
mask - (Optional) Specify the mask.
<hex 0x0-0xffff> - Specify the mask.
flag - (Optional) Specify the TCP flag fields .
all - Specify that the TCP flag field mask will be set to all.
urg - Specify that the TCP flag field mask will be set to urg.
ack - Specify that the TCP flag field mask will be set to ack.
psh - Specify that the TCP flag field mask will be set to psh.
rst - Specify that the TCP flag field mask will be set to rst.
syn - Specify that the TCP flag field mask will be set to syn.
fin - Specify that the TCP flag field mask will be set to fin.
udp - Specify that the rule applies to UDP traffic.
src_port - (Optional) Specify the range of UDP source port range.
<value 0-65535> - Enter the source port value here. This value must be between 0 and
65535.
mask - (Optional) Specify the mask.
<hex 0x0-0xffff> - Specify the mask.
dst_port - (Optional) Specify the range of UDP destination port mask.
<value 0-65535> - Enter the destination port value here. This value must be between 0
and 65535.
mask - (Optional) Specify the mask.
<hex 0x0-0xffff> - Specify the mask.
protocod_id - Specify that the rule applies to the value of IP protocol ID traffic.
<value 0-255> - Enter the protocol ID value here. This value must be between 0 and 255.
user_define - (Optional) Specify that the rule applies to the IP protocol ID and the mask options
behind the IP header length is 20 bytes.
<hex 0x0-0xffffffff> - Enter the user-defined IP protocol ID mask here.
mask - (Optional) Specify the mask.
<hex 0x0-0xffffffff> - Specify the mask.
packet_content - Specify the frame content pattern, there are 5 offsets in maximum could be
configure. Each offset presents 16 bytes, the range of content of frame is 80 bytes(5 offsets)
in the first eighty bytes of frame.
offset_0-15 - (Optional) Specify that the mask pattern offset of the frame will be between 0
and 15.
<hex 0x0-0xffffffff> - Enter the mask pattern offset of the frame between 0 and 15 here.
offset_16-31 - (Optional) Specify that the mask pattern offset of the frame will be between 16
and 31.
