xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
238
<hex 0x0-0xffffffff> - Enter the mask pattern offset of the frame between 16 and 31 here.
offset_32-47 - (Optional) Specify that the mask pattern offset of the frame will be between 32
and 47.
<hex 0x0-0xffffffff> - Enter the mask pattern offset of the frame between 32 and 47 here.
offset_48-63 - (Optional) Specify that the mask pattern offset of the frame will be between 48
and 63.
<hex 0x0-0xffffffff> - Enter the mask pattern offset of the frame between 48 and 63 here.
offset_64-79 - (Optional) Specify that the mask pattern offset of the frame will be between 64
and 79.
<hex 0x0-0xffffffff> - Enter the mask pattern offset of the frame between 64 and 79 here.
ipv6 - Specify the rule applies to IPv6 fields.
class - (Optional) Specify the value of IPv6 class.
<value 0-255> - Enter the IPv6 class value here. This value must be between 0 and 255.
flowlabel - (Optional) Specify the value of IPv6 flowlabel.
<hex 0x0-0xffff> - Enter the IPv6 flowlabel here.
source_ipv6 - (Optional) Specify the value of IPv6 source address.
<ipv6addr> - Enter the IPv6 source address used for this configuration here.
mask - (Optional) Specify the mask.
<ipv6mask> - Specify the mask.
destination_ipv6 - (Optional) Specify the value of IPv6 destination address.
<ipv6addr> - Enter the IPv6 destination address used for this configuration here.
mask - (Optional) Specify the mask.
<ipv6mask> - Specify the mask.
tcp - (Optional) Specify to configure the TCP parameters.
src_port - Specify the value of the IPv6 Layer 4 TCP source port.
<value 0-65535> - Enter the TCP source port value here. This value must be between 0
and 65535.
mask - Specify an additional mask parameter that can be configured.
<hex 0x0-0xffff> - Enter the TCP source port mask value here.
dst_port - (Optional) Specify the value of the IPv6 Layer 4 TCP destination port.
<value 0-65535> - Enter the TCP destination port value here. This value must be between
0 and 65535.
mask - Specify an additional mask parameter that can be configured.
<hex 0x0-0xffff> - Enter the TCP destination port mask value here.
udp - (Optional) Specify to configure the UDP parameters.
src_port - Specify the value of the IPv6 Layer 4 UDP source port.
<value 0-65535> - Enter the UDP source port value here. This value must be between 0
and 65535.
mask - Specify an additional mask parameter that can be configured.
<hex 0x0-0xffff> - Enter the UDP source port mask value here.
dst_port - Specify the value of the IPv6 Layer 4 UDP destination port.
<value 0-65535> - Enter the UDP destination port value here. This value must be between
0 and 65535.
mask - Specify an additional mask parameter that can be configured.
<hex 0x0-0xffff> - Enter the UDP destination port mask value here.
icmp - (Optional) Specify to configure the ICMP parameters used.
type - Specify that the rule applies to the value of ICMP type traffic.
<value 0-255> - Enter the ICMP type traffic value here. This value must be between 0 and
255.
code - Specify that the rule applies to the value of ICMP code traffic.
<value 0-255> - Enter the ICMP code traffic value here. This value must be between 0 and
255.
port - Specify the list of ports to be included in this configuration.
<portlist> - Enter a list of ports used for the configuration here.
all - Specify that all the ports will be used for this configuration.
permit - Specify the packets that match the access profile are permit by the Switch.
deny - Specify the packets that match the access profile are filtered by the Switch.
time_range - (Optional) Specify name of this time range entry.
<range_name> - Enter the time range here.
