xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
392
To configure the RPL port for a specific R-APS VLAN:
DGS-3120-24TC:admin#config erps raps_vlan 4094 rpl_port west
Command: config erps raps_vlan 4094 rpl_port west
Success.
DGS-3120-24TC:admin#
To configure the protected VLAN for a specific R-APS VLAN:
DGS-3120-24TC:admin# config erps raps_vlan 4094 protected_vlan add vlanid 10-20
Command: config erps raps_vlan 4094 protected_vlan add vlanid 10-20
Success.
DGS-3120-24TC:admin#
To configure the ERPS timers for a specific R-APS VLAN:
DGS-3120-24TC:admin#config erps raps_vlan 4094 timer holdoff_time 100
guard_time 1000 wtr_time 10
Command: config erps raps_vlan 4094 timer holdoff_time 100 guard_time 1000
wtr_t
ime 10
Success.
DGS-3120-24TC:admin#
To configure the ring state of the ERPS:
DGS-3120-24TC:admin#config erps raps_vlan 4094 state enable
Command: config erps raps_vlan 4094 state enable
Success.
DGS-3120-24TC:admin#
To configure a sub-ring connected to another ring:
DGS-3120-24TC:admin# config erps raps_vlan 4094 add sub_ring raps_vlan 4093
Command: config erps raps_vlan 4094 add sub_ring raps_vlan 4093
Success.
DGS-3120-24TC:admin#
