D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
395
Example
To display ERPS information:
DGS-3120-24TC:admin# show erps
Command: show erps
ERPS Information
Global Status : Enabled
Log Status : Disabled
Trap Status : Disabled
------------------------
R-APS VLAN : 4092
Ring Status : Enabled
West Port : 5 (Blocking)
East Port : 7 (Forwarding)
RPL Port : West Port
RPL Owner : Enabled (Active)
Protected VLANs : 100-300, 4092, 4093
Ring MEL : 2
Holdoff Time : 0 milliseconds
Guard Time : 500 milliseconds
WTR Time : 5 minutes
Current Ring State : Idle
------------------------
R-APS VLAN : 4093
Ring Status : Enabled
West Port : Virtual Channel
East Port : 10 (Forwarding)
RPL Port : None
RPL Owner : Disabled
Protected VLANs : 200-220
Ring MEL : 2
Holdoff Time : 0 milliseconds
Guard Time : 500 milliseconds
WTR Time : 5 minutes
Current Ring State : Idle
------------------------
Total Ring: 2
DGS-3120-24TC:admin#
DGS-3120-24TC:admin# show erps raps_vlan 4092 sub_ring
Command: show erps raps_vlan 4092 sub_ring
R-APS VLAN: 4092
Sub-Ring R-APS VLAN TC Propagation State
------------------- ---------------------
4093 Enable
4094 Enable
--------------------------------------------
Total Sub-Ring Connected: 2
DGS-3120-24TC:admin#

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
