D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
451
Example
To enable the data driven learning of an IGMP snooping group on the default VLAN:
DGS-3120-24TC:admin# config igmp_snooping data_driven_learning vlan default
state enable
Command: config igmp_snooping data_driven_learning vlan default state enable
Success.
DGS-3120-24TC:admin#
42-14 config igmp_snooping data_driven_learning
max_learned_entry (EI and SI Mode Only)
Description
This command is used to configure the maximum number of groups that can be learned by data
driven.
When the table is full, the system will stop the learning of the new data-driven groups. Traffic for
the new groups will be dropped.
Format
config igmp_snooping data_driven_learning max_learned_entry <value 1-1024>
Parameters
max_learned_entry - Specify the maximum number of groups that can be learned by data
driven. The suggested default setting is 56. This default setting may vary depending on
projects.
<value 1-1024> - Enter the maximum learning entry value here. This value must be between
1 and 1024.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To set the maximum number of groups that can be learned by data driven:
DGS-3120-24TC:admin# config igmp_snooping data_driven_learning
max_learned_entry 50
Command: config igmp_snooping data_driven_learning max_learned_entry 50
Success.
DGS-3120-24TC:admin#
