D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
457
Parameters
vlan - (Optional) Specify the name of the VLAN for which you want to view IGMP snooping
forwarding table information.
<vlan_name 32> - Enter the VLAN name here. The VLAN name can be up to 32 characters
long.
vlanid - (Optional) Specify the ID of the VLAN for which you want to view IGMP snooping
forwarding table information.
<vlanid_list> - Enter the VLAN ID list here.
If no parameter is specified, the system will display all current IGMP snooping forwarding table
entries of the Switch.
Restrictions
None.
Example
To show all IGMP snooping forwarding entries located on the Switch:
DGS-3120-24TC:admin# show igmp_snooping forwarding
Command: show igmp_snooping forwarding
VLAN Name : default
Source IP : 10.90.90.114
Multicast Group: 225.0.0.0
Port Member : 2,7
VLAN Name : default
Source IP : 10.90.90.10
Multicast Group: 225.0.0.1
Port Member : 2,5
VLAN Name : default
Source IP : 10.90.90.20
Multicast Group: 225.0.0.2
Port Member : 2,8
Total Entries : 3
DGS-3120-24TC:admin#
42-20 show router_ports
Description
This command is used to display the currently configured router ports on the Switch.
Format
show router_ports [vlan <vlan_name 32> | vlanid <vlanid_list> | all ] {[static | dynamic |
forbidden]}

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
