D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
458
Parameters
vlan - Specify the name of the VLAN on which the router port resides.
<vlan_name 32> - Enter the VLAN name here. The VLAN name can be up to 32 characters
long.
vlanid - Specify the ID of the VLAN on which the router port resides.
<vlanid_list> - Enter the VLAN ID list here.
all - Specify all VLANs on which the router port resides.
static - (Optional) Displays router ports that have been statically configured.
dynamic - (Optional) Displays router ports that have been dynamically configured.
forbidden - (Optional) Displays forbidden router ports that have been statically configured.
If no parameter is specified, the system will display all currently configured router ports on the
Switch.
Restrictions
None.
Example
To display router ports:
DGS-3120-24TC:admin#show router_ports all
Command: show router_ports all
VLAN Name : default
Static Router Port : 1:1-1:10
Dynamic Router Port :
Router IP :
Forbidden Router Port : 1:11-1:12
Total Entries: 1
DGS-3120-24TC:admin#
42-21 show igmp_snooping statistics counter
Description
This command is used to display the statistics counter for IGMP protocol packets that are received
by the Switch since IGMP snooping was enabled.
Format
show igmp_snooping statistic counter [vlan <vlan_name> | vlanid <vlanid_list> | ports
<portlist>]

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
