D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
465
Parameters
ports - Specify the ports used for this configuration.
<portlist> - Enter the list of ports used for this configuration here.
all - Specify that all the ports will be used.
arp_inspection - (Optional) Specify that the ARP inspection option will be configured.
strict - In this mode, all packets are dropped by default until a legal ARP or IP packets are
detected.
loose - In this mode, all packets are forwarded by default until an illegal ARP or broadcast IP
packets are detected. If not specified strict or loose, default is strict.
disable - Disable ARP inspection function. The default value is disabled.
ip_inspection - (Optional) Specify that the IP inspection option will be configured.
enable - Enable IP inspection function. The legal IP packets will be forward, while the illegal
IP packets will be dropped.
disable - Disable IP inspection function. The default value is disabled.
nd_inspection - Specify that the ND inspection option will be configured.
enable - Specify that the ND inspection option will be enabled. The legal ND packets will be
forwarded while the illegal packets will be dropped.
disable - Specify that the ND inspection option will be disabled. This is the default option.
protocol - (Optional) Specify the version used.
ipv4 - Only IPv4 packets will be checked.
ipv6 - Specify that only IPv6 packets will be checked.
all - Specify that all packets will be checked.
allow_zeroip - (Optional) Specify whether to allow ARP packets with a source IP address of
0.0.0.0. If the IP address 0.0.0.0 is not configured in the binding list and this setting is enabled,
ARP packets with the source IP address of 0.0.0.0 will be allowed; If the IP address 0.0.0.0 is
not configured in the binding list and this setting is disabled, ARP packets with the source IP
address of 0.0.0.0 will not be allowed. This option does not affect the IMPB ACL Mode.
enable - Specify that the allow zero IP option will be enabled.
disable - Specify that the allow zero IP option will be disabled.
forward_dhcppkt - (Optional) By default, DHCP packets with a broadcast DA will be flooded.
When set to disabled, the broadcast DHCP packet received by the specified port will not be
forwarded. This setting is effective when DHCP Snooping is enabled, in this case DHCP
packets trapped by the CPU must be forwarded by the software. This setting controls the
forwarding behavior in this situation.
enable - Specify that the forward DHCP packets option will be enabled.
disable - Specify that the forward DHCP packets option will be disabled.
stop_learning_threshold - (Optional) When the number of blocked entries exceeds the
threshold, the port will stop learning new addresses. Packets with a new address will be
dropped.
<int 0-500> - Enter the stop learning threshold value here. This value must be between 0 and
500.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To enable IMPB on port 1:
DGS-3120-24TC:admin#config address_binding ip_mac ports 1:1 arp_inspection
strict
Command: config address_binding ip_mac ports 1:1 arp_inspection strict
Success.
DGS-3120-24TC:admin#

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
