D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
493
Format
config ip standard access_list <list_name 16> [add | delete] <network_address> [deny |
permit]
Parameters
<list_name 16> - Enter the name of the access list.
add - Add the entry to the access list.
delete - Delete the entry from the access list.
<network_address> - Enter the network address as the filter condidtion of the access list.
deny - The network matched will be denied.
permit - The network matched will be permitted.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To add an entry to the access list:
DGS-3120-24TC:admin#config ip standard access_list list1 add 10.10.10.0/24
permit
Command: config ip standard access_list list1 add 10.10.10.0/24 permit
Success.
DGS-3120-24TC:admin#
45-3 delete ip standard access_list
Description
This command is used to delete an access list identified by the access list name.
Format
delete ip standard access_list [list_name <list_name 16> | all]
Parameters
list_name - Specify the name of the access list.
<list_name 16> - Enter the name of the access list.
all - specify to remove all access list.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
