D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
511
47-6 config ipv6 nd ra ipif (RI Mode Only)
Description
This command is used to configure the RA parameters of a specified interface.
Format
config ipv6 nd ra ipif <ipif_name 12> {state [enable | disable] | life_time <sec 0-9000> |
reachable_time <millisecond 0-3600000> | retrans_time <millisecond 0-4294967295> |
hop_limit <value 0-255> | managed_flag [enable | disable] | other_config_flag [enable |
disable] | min_rtr_adv_interval <sec 3-1350> | max_rtr_adv_interval <sec 4-1800>}(1)
Parameters
<ipif_name 12> - Specify the name of the interface.
state - Specify the router advertisement status.
enable - Enable the router advertisement state.
disable - Disable the router advertisement state.
life_time - Specify the lifetime of the router as the default router, in seconds.
<sec 0-9000> - Specify the time between 0 and 9000 seconds.
reachable_time - Specify the amount of time that a node can consider a neighboring node
reachable after receiving a reachability confirmation, in milliseconds.
<millisecond 0-3600000> - Specify the time between 0 and 3600000 milliseconds.
retrans_time - Specify the amount of time that a node can consider a neighboring node
reachable after receiving a reachability confirmation, in milliseconds.
<millisecond 0-4294967295> - Specify the time between 0 and 4294967295 milliseconds.
hop_limit - Specify the default value of the hop limit field in the IPv6 header for packets sent by
hosts that receive this RA message.
<value 0-255> - Specify the value between 0 and 255.
managed_flag - Specify to enable or disable the function.
enable - When set to enable, it indicates that hosts receiving this RA must use a stateful
address configuration protocol to obtain an address, in addition to the addresses derived
from the stateless address configuration.
disable - Set to disable to stop hosts receiving the RA from using a stateful address
configuration to obtain an address.
other_config_flag - Specify to enable or disable the function.
enable - When set to enable, it indicates that hosts receiving this RA must use a stateful
address configuration protocol to obtain on-address configuration information.
disable - Set to disable to stop hosts receiving this RA from using a stateful address
configuration protocol to obtain on-address configuration information.
min_rtr_adv_interval - Specify the minimum time allowed between sending unsolicited multicast
Router Advertisements from the interface, in seconds. It must be no less than 3 seconds and
no greater than .75 * MaxRtrAdvInterval. The default is 0.33 * MaxRtrAdvInterval.
<sec 3-1350> - Specify the time between 3 and 1350 seconds.
max_rtr_adv_interval - Specify the maximum time allowed between sending unsolicited
multicast Router Advertisements from the interface, in seconds. It must be no less than 4
seconds and no greater than 1800 seconds. The default is 600 seconds.
<sec 4-1800> - Specify the time between 4 and 1800 seconds.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
