D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
552
DGS-3120-24TC:admin#show link_aggregation
Command: show link_aggregation
Link Aggregation Algorithm = MAC-Source-Dest
Group ID : 1
Type : LACP
Master Port : 1:5
Member Port : 1:5-1:7
Active Port :
Status : Disabled
Flooding Port :
Trap : Disabled
Total Entries : 1
DGS-3120-24TC:admin#
52-6 config lacp_port
Description
This command is used to configure per-port LACP mode.
Format
config lacp_port <portlist> mode [active | passive]
Parameters
lacp_port - Specified a range of ports to be configured.
<portlist> - Enter the list of port used for the configuration here.
mode - Specify the LACP mode used.
active - Specify to set the LACP mode as active.
passive - Specify to set the LACP mode as passive.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To config port LACP mode:
DGS-3120-24TC:admin# config lacp_port 1:1-1:12 mode active
command: config lacp_port 1:1-1:12 mode active
Success.
DGS-3120-24TC:admin#

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
