D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
51
Format
delete 802.1x guest_vlan <vlan_name 32>
Parameters
<vlan_name 32> - Enter the VLAN name here. The VLAN name can be up to 32 characters long.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To delete the guest VLAN named “guestVLAN”:
DGS-3120-24TC:admin# delete 802.1x guest_vlan guestVLAN
Command: delete 802.1x guest_vlan guestVLAN
Success.
DGS-3120-24TC:admin#
4-19 config 802.1x guest_vlan
Description
This command is used to configure guest VLAN setting. If the specific port state is changed from
enabled state to disable state, this port will move to its original VLAN.
Format
config 802.1x guest_vlan ports [<portlist> | all] state [enable | disable]
Parameters
ports - A range of ports enable or disable guest VLAN function.
<portlist> - Enter the list of ports used for the configuration here.
all - Specify that all the port will be included in this configuration.
state - Specify the guest VLAN port state of the configured ports.
enable - Specify to join the guest VLAN.
disable - Specify to be removed from the guest VLAN.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To enable from port 1:2 to 1:8 to configure 802.1X guest VLAN:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
