D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
560
To configure port 1:1-1:5 to transmit and receive:
DGS-3120-24TC:admin#config lldp ports 1:1-1:5 admin_status tx_and_rx
Command: config lldp ports 1:1-1:5 admin_status tx_and_rx
Success.
DGS-3120-24TC:admin#
To enable ports 1-2 for manage address entry:
DGS-3120-24TC:admin#config lldp ports 1:1-1:2 mgt_addr ipv4 192.168.254.10
enable
Command: config lldp ports 1:1-1:2 mgt_addr ipv4 192.168.254.10 enable
Success
DGS-3120-24TC:admin#
To configure exclude the system name TLV from the outbound LLDP advertisements for all ports:
DGS-3120-24TC:admin#config lldp ports all basic_tlvs system_name enable
Command: config lldp ports all basic_tlvs system_name enable
Success.
DGS-3120-24TC:admin#
To configure exclude the vlan nameTLV from the outbound LLDP advertisements for all ports:
DGS-3120-24TC:admin#config lldp ports all dot1_tlv_protocol_vid vlan default
enable
Command: config lldp ports all dot1_tlv_protocol_vid vlan default enable
Success.
DGS-3120-24TC:admin#
To configure exclude the port and protocol VLAN ID TLV from the outbound LLDP advertisements
for all ports:
DGS-3120-24TC:admin# config lldp ports all dot1_tlv_protocol_vid vlanid 1-3
enable
Command: config lldp ports all dot1_tlv_protocol_vid vlanid 1-3 enable
Success.
DGS-3120-24TC:admin#
To configure exclude the VLAN name TLV from the outbound LLDP advertisements for all ports:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
