D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
561
DGS-3120-24TC:admin# config lldp ports all dot1_tlv_vlan_name vlanid 1-3
enable
Command: config lldp ports all dot1_tlv_vlan_name vlanid 1-3 enable
Success.
DGS-3120-24TC:admin#
To configure exclude the protocol identity TLV from the outbound LLDP advertisements for all
ports:
DGS-3120-24TC:admin# config lldp ports all dot1_tlv_protocol_identity all
enable
Command: config lldp ports all dot1_tlv_protocol_identity all enable
Success.
DGS-3120-24TC:admin#
To configure exclude the MAC/PHY configuration/status TLV from the outbound LLDP
advertisements for all ports:
DGS-3120-24TC:admin# config lldp ports all dot3_tlvs
mac_phy_configuration_status enable
Command: config lldp ports all dot3_tlvs mac_phy_configuration_status enable
Success.
DGS-3120-24TC:admin#
53-6 config lldp forward_ message
Description
This command is used to configure forwarding of LLDP PDU packet when LLDP is disabled.
Format
config lldp forward_message [enable | disable]
Parameters
None.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure LLDP to forward LLDP PDUs:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
