D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
570
PPVID Enable : Enable
VLAN Name Entries
Entry 1
VLAN ID : 1
VLAN Name : V1
Entry 2
VLANID : 2
VLAN Name : V2
Entry 3
VLAN ID : 3
VLAN Name : V3
Protocol Identity Entries
Entry 1
Protocol index : 1
Protocol id : 00 16 42 42 03 00 01 01
Protocol Name : GVRP
Entry 2
Protocol index : 2
Protocol id : 00 27 42 42 03 00 00 02
Protocol Name : STP
MAC/PHY Configuration/Status
Auto-negotiation support : supported
Auto-negotiation status : enabled
Auto-negotiation advertised capability : xxxx (hex)
Auto-negotiation operational MAU type : 0010 (hex)
Power Via MDI
Port class : PSE
PSE MDI pnower support : supported
PSE MDI power state : enabled
PSE pairs control ability : uncontrollable
PSE power pair : signal
power class : 3
Link Aggregation
Aggregation capability : aggregated
Aggregation status : currently in aggregation
Aggregated port ID : 1
Maximum Frame Size : 1000
Unknown TLVs
Entry 1
Unknown TLV type : 30
Unknown TLV Information Bytes : XX XX XX XX XX XX(hex)
Entry 2

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
