D-Link xStack DGS-3120 Series

To Next Page

To Previous Page

xStack

DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide

579

Location Information :

Location Subtype: CivicAddress

Location Information :

Extended Power Via MDI

Power Device Type: PD Device

Power Priority : High

Power Source : From PSE

Power Request : 8 Watts

Inventory Management:

Hardware Revision :

Firmware Revision :

Software Revision :

Serial Number :

Manufacturer Name :

Model Name :

Asset ID :

DGS-3120-24TC:admin#
