D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
599
Parameters
ports - Specify a range of ports for configuring the MAC-based Access Control function
parameters.
<portlist> - Enter the list of port used for this configuration here.
all - Specify all existed ports of switch for configuring the MAC-based Access Control function
parameters.
state - (Optional) Specify whether the port’s MAC-based Access Control function is enabled or
disabled.
enable - Specify that the port's MAC-based Access Control states will be enabled.
disable - Specify that the port's MAC-based Access Control states will be disabled.
mode - (Optional) Specify the MAC-based access control port mode used.
port_based - Specify that the MAC-based access control port mode will be set to port-based.
host_based - Specify that the MAC-based access control port mode will be set to host-based.
aging_time - (Optional) A time period during which an authenticated host will be kept in an
authenticated state. When the aging time has timed-out, the host will be moved back to
unauthenticated state.
infinite - If the aging time is set to infinite, it means that authorized clients will not be aged out
automatically.
<min 1-1440> - Enter the aging time value here. This value must be between 1 and 1440
minutes.
block_time - (Optional) If a host fails to pass the authentication, the next authentication will not
start within the block time unless the user clears the entry state manually. If the block time is
set to 0, it means do not block the client that failed authentication.
<sec 0-300> -Enter the block time value here. This value must be between 0 and 300
seconds.
max_users - (Optional) Specify maximum number of users per port.
<value 1-1000> - Enter the maximum number of users per port here. This value must be
between 1 and 1000.
no_limit - Specify to not limit the maximum number of users on the port. The default value is
128.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure an unlimited number of maximum users for MAC-based Access Control on ports 1:1
to 1:8:
DGS-3120-24TC:admin# config mac_based_access_control ports 1:1-1:8 max_users
no_limit
Command: config mac_based_access_control ports 1:1-1:8 max_users no_limit
Success.
DGS-3120-24TC:admin#
To configure the MAC-based Access Control timer parameters to have an infinite aging time and a
block time of 120 seconds on ports 1:1 to 1:8:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
