D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
640
DGS-3120-24TC:admin# show mld_snooping group data_driven
Command: show mld_snooping group data_driven
Source/Group : NULL/FF1E::5
VLAN Name/VID : default/1
Member Ports :
Router Ports : 24
UP Time : 100
Expiry Time : 200
Filter Mode : EXCLUDE
Total Entries : 1
DGS-3120-24TC:admin#
63-9 show mld_snooping forwarding
Description
This command is used to display the Switch’s current MLD snooping forwarding table. It provides
an easy way for users to check the list of ports that the multicast group that comes from specific
sources will be forwarded to. The packet comes from the source VLAN. They will be forwarded to
the forwarding VLAN. The MLD snooping further restricts the forwarding ports.
Format
show mld_snooping forwarding {[vlan <vlan_name 32> | vlanid <vlanid_list>]}
Parameters
vlan - (Optional) Specify the name of the VLAN for which you want to view MLD snooping
forwarding table information.
<vlan_name 32> - Enter the VLAN name here. The VLAN name can be up to 32 characters
long.
vlanid - (Optional) Specify the ID of the VLAN for which you want to view MLD snooping
forwarding table information.
<vlanid_list> - Enter the VLAN ID list here.
If no parameter is specified, the system will display all current MLD snooping forwarding table
entries of the Switch.
Restrictions
None.
Example
To show all MLD snooping forwarding entries located on the Switch.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
