D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
639
Restrictions
None.
Example
To show an MLD snooping group when MLD v2 is supported:
The first item means that for ports 1-2, the data from the 2001::1/FE1E::1 will be forwarded.
The second item means that for port 3, the data from the 2002::2/FE1E::1 must not be forwarded.
The third item means that for ports 4-5, the data from FE1E::2 will be forwarded, MLD v1 group
doesn't care about the source address.
The fourth item is a data-driven learned entry. The member port list is empty. The multicast
packets will be forwarded to the router ports. If the router port list is empty, the packet will be
dropped.
DGS-3120-24TC:admin# show mld_snooping group
Command: show mld_snooping group
Source/Group : 2001::1/FE1E::1
VLAN Name/VID : default/1
Member Ports : 1-2
UP Time : 26
Expiry Time : 258
Filter Mode : INCLUDE
Source/Group : 2002::2/FE1E::1
VLAN Name/VID: : default/1
Member Ports : 3
UP Time : 29
Expiry Time : 247
Filter Mode : EXCLUDE
Source/Group : NULL/FE1E::2
VLAN Name/VID : default/1
Member Ports : 4-5
UP Time : 40
Expiry Time : 205
Filter Mode : EXCLUDE
Source/Group : NULL/FF1E::5
VLAN Name/VID : default/1
Reports : 0
Member Ports :
Router Ports : 24
UP Time : 100
Expiry Time : 200
Filter Mode : EXCLUDE
Total Entries : 4
DGS-3120-24TC:admin#
