D-Link xStack DGS-3120 Series - Page 711

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
706
DGS-3120-24TC:admin#config ospf ipif System priority 2 hello_interval 20 metric
2 state enable
Command: config ospf ipif System priority 2 hello_interval 20 metric 2 state
enable
Success.
DGS-3120-24TC:admin#
70-2 create ospf aggregation
Description
This command is used to create an OSPF area aggregation entry.
Format
create ospf aggregation <area_id> <network_address> lsdb_type [summary {advertise
[enable | disable]} | nssa_ext {advertise [enable | disable]}]
Parameters
<area_id> - A 32-bit number in the form of an IP address (xxx.xxx.xxx.xxx) that uniquely
identifies the OSPF area in the OSPF domain.
<network_address> - The IP address that uniquely identifies the network that corresponds to
the OSPF Area. The network address format is 'IP address/prefix length'.
lsdb_type - Specify the Link-State Database (LSDB) type of address aggregation.
summary - Specify the LSDB type as summary.
advertise - (Optional) Allows for the advertisement of the summary LSAs.
enable - Specify that the advertisement trigger will be enabled.
disable - Specify that the advertisement trigger will be disabled.
nssa_ext - Specify the LSDB type as a Not-So-Stub Area External Route (NSSA EXT).
advertise - (Optional) Allows for the advertisement of aggregated NSSA external route.
enable - Specify that the advertisement trigger will be enabled.
disable - Specify that the advertisement trigger will be disabled.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To create an OSPF area aggregation entry:
DGS-3120-24TC:admin#create ospf aggregation 10.48.74.122 192.168.0.1/16
lsdb_type summary
Command: create ospf aggregation 10.48.74.122 192.168.0.1/16 lsdb_type summary
Success.
DGS-3120-24TC:admin#
