D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
707
70-3 config ospf aggregation
Description
This command is used to configure the OSPF area aggregation settings.
Format
config ospf aggregation <area_id> <network_address> lsdb_type [summary {advertise
[enable | disable]} | nssa_ext {advertise [enable | disable]}]
Parameters
<area_id> - A 32-bit number in the form of an IP address (xxx.xxx.xxx.xxx) that uniquely
identifies the OSPF area in the OSPF domain.
<network_address> - The IP address that uniquely identifies the network that corresponds to
the OSPF Area. The network address format is 'IP address/prefix length'.
lsdb_type - Specify the Link-State Database (LSDB) type of address aggregation.
summary - Specify the LSDB type as summary.
advertise - (Optional) Allows for the advertisement of the summary LSAs.
enable - Specify that the advertisement trigger will be enabled.
disable - Specify that the advertisement trigger will be disabled.
nssa_ext - Specify the LSDB type as a Not-So-Stub Area External Route (NSSA EXT).
advertise - (Optional) Allows for the advertisement of aggregated NSSA external route.
enable - Specify that the advertisement trigger will be enabled.
disable - Specify that the advertisement trigger will be disabled.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the OSPF area aggregation settings:
DGS-3120-24TC:admin#config ospf aggregation 10.48.74.122 192.168.0.1/16
lsdb_type summary advertise enable
Command: config ospf aggregation 10.48.74.122 192.168.0.1/16 lsdb_type summary
advertise enable
Success.
DGS-3120-24TC:admin#
70-4 delete ospf aggregation
Description
This command is used to delete an OSPF area aggregation entry.
Format
delete ospf aggregation <area_id> <network_address> lsdb_type [summary | nssa_ext]

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
