D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
708
Parameters
<area_id> - A 32-bit number in the form of an IP address (xxx.xxx.xxx.xxx) that uniquely
identifies the OSPF area in the OSPF domain.
<network_address> - The IP address that uniquely identifies the network that corresponds to
the OSPF Area. The network address format is 'IP address/prefix length'.
lsdb_type - Specify the LSDB type.
summary - Specify the summary type.
nssa_ext - Specify the NSSA EXT type.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To delete an OSPF area aggregation entry:
DGS-3120-24TC:admin#delete ospf aggregation 10.48.74.122 192.168.0.1/16
lsdb_type summary
Command: delete ospf aggregation 10.48.74.122 192.168.0.1/16 lsdb_type summary
Success.
DGS-3120-24TC:admin#
70-5 show ospf aggregation
Description
This command is used to display the current OSPF area aggregation settings.
Format
show ospf aggregation {<area_id>}
Parameters
<area_id> - (Optional) Enter the area ID used here.
Restrictions
None.
Example
To display OSPF area aggregation settings:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
