DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide

801

Example

To display PIM-SSM state and group range:

DGS-3120-24TC:admin#show pim-ssm

Command: show pim-ssm

SSM Service Model State : Enabled

SSM Group : 232.0.0.0/8

DGS-3120-24TC:admin#
