D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
822
82-2 config dot1v_protocol_group add protocol
Description
This command is used to add a protocol to a protocol group. The selection of a protocol can be a
pre-defined protocol type or a user defined protocol.
Format
config dot1v_protocol_group [group_id <int 1-16> | group_name <name 32>] [add protocol
[ethernet_2 | ieee802.3_snap | ieee802.3_llc] <protocol_value> | delete protocol [ethernet_2 |
ieee802.3_snap | ieee802.3_llc] <protocol_value>]
Parameters
group_id - The ID of the protocol group which is used to identify a set of protocols.
<int 1-16> - Enter the group ID.
group_name - The name of the protocol group.
<name 32> - Enter the group name here. This name can be up to 32 characters long.
add - Specify that the protocol will be added to the specified group.
delete - Specify that the protocol will be removed from the specified group.
protocol - The protocol value is used to identify a protocol of the frame type specified.
ethernet_2 - Specify that the Ethernet 2 protocol will be used.
ieee802.3_snap - Specify that the IEEE 802.3 Snap protocol will be used.
ieee802.3_llc - Specify that the IEEE 802.3 LLC protocol will be used.
<protocol_value> - Enter the protocol value here.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To add a protocol ipv6 to protocol group 10:
DGS-3120-24TC:admin# config dot1v_protocol_group group_id 10 add protocol
ethernet_2 86DD
Command: config dot1v_protocol_group group_id 10 add protocol ethernet_2 86DD
Success.
DGS-3120-24TC:admin#
82-3 delete dot1v_protocol_group
Description
This command is used to delete a protocol group
Format
delete dot1v_protocol_group [group_id <int 1-16> | group_name <name 32> | all]

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
