D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
823
Parameters
group_id - Specify the group ID to be deleted.
<int 1-16> - Enter the group ID used here.
group_name - Specify the name of the group to be deleted.
<name 32> - Enter the group name here. This name can be up to 32 characters long.
all - Specify that all the protocol group will be deleted.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To delete protocol group 100:
DGS-3120-24TC:admin# delete dot1v_protocol_group group_id 100
Command: delete dot1v_protocol_group group_id 100
Success.
DGS-3120-24TC:admin#
82-4 show dot1v_protocol_group
Description
This command is used to display the protocols defined in a protocol group.
Format
show dot1v_protocol_group {[group_id <int 1-16> | group_name <name 32>]}
Parameters
group_id - (Optional) Specify the ID of the group to be displayed.
<int 1-16> - Enter the group ID used here.
group_name - (Optional) Specify the name of the protocol group to be displayed.
<name 32> - Enter the group name here. This name can be up to 32 characters long.
If no group ID is not specified, all the configured protocol groups will be displayed.
Restrictions
None.
Example
To display the protocol group ID 10:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
