D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
824
DGS-3120-24TC:admin# show dot1v_protocol_group group_id 10
Command: show dot1v_protocol_group group_id 10
Protocol Protocol Frame Type Protocol
Group ID Group Name Value
--------- --------------- ------------ ------------
100 General Group EthernetII 86dd
Success.
DGS-3120-24TC:admin#
82-5 config port dot1v ports
Description
This command is used to assign the VLAN for untagged packets ingress from the port list based
on the protocol group configured. This assignment can be removed by using the delete
protocol_group option.
When priority is not specified in the command, the port default prority will be the priority for those
untagged packets classified by the protocol vlan.
Format
config port dot1v ports [<portlist> | all] [add protocol_group [group_id <int 1-16> |
group_name <name 32>] [vlan <vlan_name 32> | vlanid <id>] {priority <value 0-7>} | delete
protocol_group [group_id <int 1-16> | all]]
Parameters
<portlist> - Enter a list of ports used for the configuration here.
all - Specify that all the ports will be used for this configuration.
add - Specify that the group specified will be added.
protocol_group - Specify that parameters for the group will follow.
group_id - Specify the group ID of the protocol group.
<int 1-16> - Enter the group ID used here.
group_name - Specify the name of the protocol group.
<name 32> - Enter the name of the group used here. This name can be up to 32 characters
long.
vlan - The VLAN that is to be associated with this protocol group on this port.
<vlan_name 32> - Enter the name of the VLAN here. This name can be up to 32 characters
long.
vlanid - Specify the VLAN ID.
<id> - Enter the VLAN ID used here.
priority - (Optional) Specify the priority to be associated with the packet which has been
classified to the specified VLAN by the protocol.
<value 0-7> - Enter the priority value here. This value must be between 0 and 7.
delete - Specify that the group specified will be deleted.
protocol_group - Specify that parameters for the group will follow.
group_id - Specify the group ID of the protocol group.
<int 1-16> - Enter the group ID used here.
all - Specify that all the groups will be deleted.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
