D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
883
89-14 config ecmp algorithm (RI Mode Only)
Description
This command is used to configure the ECMP route load- balancing algorithm. It is effective for
ECMP routing. ECMP routing can be adopted either by OSPF dynamic routes or by static routes
which are configured with equal weight.
Format
config ecmp algorithm {ip_destination | [ip_source | crc_low | crc_high] | tcp_udp_port}
Parameters
ip_destination - (Optional) Specify to include the destination IP in the ECMP algorithm. This is
the default.
ip_source- (Optional) Specify to include the lower 5 bits of the source IP in the ECMP algorithm.
crc_low- (Optional) Specify to include the lower 5 bits of the CRC in the ECMP algorithm.
crc_high- (Optional) Specify to include the upper 5 bits of the CRC in the ECMP algorithm.
tcp_udp_port- (Optional) Specify to include the TCP or UDP port in the ECMP algorithm.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure ECMP algorithm:
DGS-3120-24TC:admin#config ecmp algorithm ip_destination ip_source
Command: config ecmp algorithm ip_destination ip_source
Success.
DGS-3120-24TC:admin#
89-15 show ecmp algorithm (RI Mode Only)
Description
This command is used to display the ECMP route load-balancing algorithm.
Format
show ecmp algorithm
Parameters
None.
