D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
925
Example
To show STP:
DGS-3120-24TC:admin#show stp
Command: show stp
STP Bridge Global Settings
---------------------------
STP Status : Enabled
STP Version : RSTP
Max Age : 25
Hello Time : 2
Forward Delay : 15
Max Hops : 20
TX Hold Count : 6
Forwarding BPDU : Disabled
New Root Trap : Enabled
Topology Change Trap : Enabled
NNI BPDU Address : dot1d
DGS-3120-24TC:admin#
96-5 create stp instance_id
Description
This command is used to create an MST Instance without mapping the corresponding VLANs.
Format
create stp instance_id <value 1-15>
Parameters
instance_id - Specify the MSTP instance ID. Instance 0 represents for default instance, CIST.
<value 1-15> - Enter the MSTP instance ID here. This value must be between 1 and 15.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To create MSTP instance:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
