D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
926
DGS-3120-24TC:admin#create stp instance_id 2
Command: create stp instance_id 2
Warning:There is no VLAN mapping to this instance_id!
Success.
DGS-3120-24TC:admin#
96-6 config stp instance_id
Description
This command is used to map or remove the VLAN range of the specified MST instance for the
existed MST instances.
Format
config stp instance_id <value 1-15> [add_vlan | remove_vlan] <vidlist>
Parameters
instance_id - Specify the MSTP instance ID. Instance 0 represents for default instance, CIST.
<value 1-15> - Enter the MSTP instance ID here. This value must be between 1 and 15.
add_vlan - Specify to map the specified VLAN list to an existing MST instance.
remove_vlan - Specify to delete the specified VLAN list from an existing MST instance.
<vidlist> - Specify a list of VLANs by VLAN ID.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To map a VLAN ID to an MSTP instance:
DGS-3120-24TC:admin# config stp instance_id 2 add_vlan 1-3
Command: config stp instance_id 2 add_vlan 1-3
Success.
DGS-3120-24TC:admin#
To remove a VLAN ID from an MSTP instance:
DGS-3120-24TC:admin# config stp instance_id 2 remove_vlan 2
Command: config stp instance_id 2 remove_vlan 2
Success.
DGS-3120-24TC:admin#

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
