D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
927
96-7 delete stp instance_id
Description
This command is used to delete an MST Instance.
Format
delete stp instance_id <value 1-15>
Parameters
instance_id - Specify the MSTP instance ID. Instance 0 represents for default instance, CIST.
<value 1-15> - Enter the MSTP instance ID here. This value must be between 1 and 15.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To delete an MSTP instance:
DGS-3120-24TC:admin# delete stp instance_id 2
Command: delete stp instance_id 2
Success.
DGS-3120-24TC:admin#
96-8 config stp mst_config_id
Description
This command is used to change the name or the revision level of the MST configuration
identification.
Format
config stp mst_config_id {revision_level <int 0-65535> | name <string>}
Parameters
name - (Optional) Specify the name given for a specific MST region.
<string> - Enter the MST region name here.
revision_level - (Optional) The same given name with different revision level also represents
different MST regions.
<int 0-65535> - Enter the revision level here. This value must be between 0 and 65535.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
