D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
992
Restrictions
None.
Example
To show the self information in detail:
DGS-3120-24TC:admin#show sim
Command: show sim
SIM Version : VER-1.61
Firmware Version : 4.00.015
Device Name :
MAC Address : 00-01-02-03-04-00
Capabilities : L3
Platform : DGS-3120-24TC L3 Switch
SIM State : Enabled
Role State : Candidate
Discovery Interval : 30 sec
Hold Time : 100 sec
DGS-3120-24TC:admin#
To show the candidate information in summary, if user specify candidate id, it would show
information in detail:
DGS-3120-24TC:admin#show sim candidate
Command: show sim candidates
ID MAC Address Platform / Hold Firmware Device Name
Capability Time Version
-- ----------------- -------------------------- ---- --------- ----------------
1 00-01-02-03-04-00 Product-Code L2 Switch 40 1.00-B01 Device-Name-01
2 00-55-55-00-55-00 Product-Code L3 Switch 140 4.00-B15 Device-Name-02
Total Entries: 2
DGS-3120-24TC:admin#
To show the member information in summary, if user specify member id, it will show information in
detail:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
