Monitoring of the DC-bus voltage
• The warning thresholds for monitoring are adjustable.
• The error thresholds and reset thresholds for monitoring result from the rated mains
voltage set:
Rated mains volt- Undervoltage thresholds Overvoltage thresholds
age
Warning threshold
Error threshold
Reset threshold
Warning threshold
Error threshold
Reset threshold
Setting in
Setting in
Display in
Display in
Setting in
Display in
Display in
0x2540:001
(P208.01)
0x2540:002
(P208.02)
0x2540:003
(P208.03)
0x2540:004
(P208.04)
0x2540:005
(P208.05)
0x2540:006
(P208.06)
0x2540:007
(P208.07)
• If the DC-bus voltage of the inverter falls below the undervoltage error threshold, the
"Trouble" response is triggered. The motor behaves in accordance with 0x2838:002
(P203.02).
• If the DC-bus voltage of the inverter exceeds the overvoltage error threshold, the
"Fault" response is triggered.
The motor does not restart automatically after the overvoltage monitoring function
has been activated.
Parameter
Name / value range / [default setting]
Info
0x2540:001
(P208.01)
Mains settings: Rated mains voltage
(Mains settings: Mains voltage)
•
Setting can only be changed if the inverter is
inhibi
ted.
Selection of the mains voltage for actuating the inverter.
0
230 Veff
1
400 Veff
2
480 Veff
0x2540:002
(P208.02)
Mains settings: Undervoltage warning threshold
(Mains settings: LU warn. thresh.)
0 ... [0]* ... 800 V
* Default setting depending on the size.
Setting of the warning threshold for monitoring DC bus undervoltage.
•
If the DC bus voltage falls below the threshold set, the inverter
out
puts a warning.
•
The warning is reset with a hysteresis of 10 V.
0x2540:003
(P208.03)
Mains settings: Undervoltage error threshold
(Mains settings: LU error thresh.)
•
Read only: x V
Display of the fixed error threshold for monitoring DC bus undervoltage.
•
If the DC-bus voltage falls below the threshold displayed, the "Fault"
response is triggered.
0x2540:004
(P208.04)
Mains settings: Undervoltage reset threshold
(Mains settings: LU reset thresh.)
•
Read only: x V
Display of the fixed reset threshold for monitoring DC bus undervoltage.
0x2540:005
(P208.05)
Mains settings: Overvoltage warning threshold
(Mains settings: OU warn. thresh.)
0 ... [0]* ... 800 V
* Default setting depending on the size.
Setting of the warning threshold for monitoring DC bus overvoltage.
•
If the DC bus voltage exceeds the threshold set, the inverter outputs a
warning.
•
The warning is reset with a hysteresis of 10 V.
0x2540:006
(P208.06)
Mains settings: Overvoltage error threshold
(Mains settings: OU error thresh.)
•
Read only: x V
Display of the fixed error threshold for monitoring the DC bus
overvoltage.
•
If the DC-bus voltage exceeds the threshold displayed, the "Fault"
response is triggered.
0x2540:007
(P208.07)
Mains settings: Overvoltage reset threshold
(Mains settings: OU reset thresh.)
•
Read only: x V
Display of the fixed reset threshold for monitoring DC bus overvoltage.
