Emotron VS10 - Wireless-LAN Diagnostics

5.2.6. Wireless-LAN diagnostics
The following parameters serve to diagnose the WLAN module and the WLAN
communication.
Preconditions
WLAN module has been plugged onto the interface X16 on the front of the inverter.
Parameter
Name / value range / [default setting]
Info
0x2442:001
Active WLAN settings: Active IP address
Read only
From version 02.00
Display of the active IP address.
If DHCP is activated, the active IP address usually derives from the
configured static IP address of the device.
0x2442:002
Active WLAN settings: Active netmask
Read only
From version 02.00
Display of the active netmask.
0x2442:003
Active WLAN settings: Active gateway
Read only
From version 02.00
Display of the active gateway IP address.
0x2442:004
Active WLAN settings: Active module mode
Read only
From version 02.00
Display of the active data source for the WLAN settings.
This parameter indicates whether the settings used come from the
inverter or from the WLAN module.
0 Inverter The WLAN settings saved in the inverter are used.
1
Standalone
The WLAN settings saved in the WLAN module are used.
0x2442:005
Active WLAN settings: MAC address
Read only
From version 02.00
Display of the MAC address of the WLAN module.
0x2448:001
WLAN status: Connection time
Read only
From version 02.00
Display of the connection time in [s] since the current connection was
established.
0x2448:002 WLAN status: Number of connections
Read only
From version 02.00
In access point mode: Display of the number of currently connected
clients.
In client mode: 0 ≡ not connected; 1 ≡ connected with external WLAN
network.
0x2448:003 WLAN status: Rx frame counter
Read only
From version 02.00
Display of the number of request received via WLAN.
0x2448:004
WLAN status: Error statistics
Read only
From version 02.00
Display of the quality of the WLAN connection. A display value > 0
indicates communication problemsn.
0x2449
WLAN error
Read only
From version 02.00
Bit coded display of WLAN errors.
Bit 2
WLAN error
Bit 3
Memory problem
Bit 4
WLAN connection problem
Bit 7 WLAN off
Bit 9
Client mode off
Bit 12
TCP/IP configuration error
Bit 13
Password length
Bit 14
Access denied
Related topics
 Wireless LAN (WLAN)  251
