Emotron VS10 - Network Diagnostics

5.2.4. Network diagnostics
The following parameters show some general information with regard to the network
option available and the network.
Further fieldbus-specific diagnostic parameters are described in the following subchapters.
Parameter Name / value range / [default setting] Info
0x282B:005
(P125.05)
Inverter diagnostics: Most recently used control
register
(Inverter diag.: Netw. contr.reg.)
Read only
Display of the network register for the control that was accessed last
(e. g. 0x6040 or 0x400B:1).
Format: 0xiiiiss00 (iiii = hexadecimal index, ss = hexadecimal subindex)
The lowest byte is always 0x00.
0x282B:006
(P125.06)
Inverter diagnostics: Most recently used setpoint
register
(Inverter diag.: Netw. setp.reg.)
Read only
Display of the network register for setpoint selection that was accessed
last (e. g. 0x6042 or 0x400B:3).
Format: 0xiiiiss00 (iiii = hexadecimal index, ss = hexadecimal subindex)
The lowest byte is always 0x00.
0x400B:006
(P592.06)
Process input data: Velocity mode setpoint (Process
data IN: Veloc. mode setp)
-599.0 ... [0.0] ... 599.0 Hz
Mappable parameter for defining the setpoint for operating mode "MS:
Velocity mode" via network.
If this parameter is to be used as standard setpoint source, the selec
tion
"Network [5]" must be set in 0x2860:001 (P201.01).
If this bipolar setpoint is used, the direction of rotation cannot be
controlled via the network control word. The direction of rotation is
determined by the sign of the setpoint.
0x400B:007
(P592.07)
Process input data: PID setpoint (Process data IN: PID
setpoint)
-300.00 ... [0.00] ... 300.00 PID unit
Mappable parameter for defining the setpoint for the PID control via
network.
If this parameter is to be used as standard setpoint source, the selec
tion
"Network [5]" must be set in 0x2860:002 (P201.02).
0x400B:008
(P592.08)
Process input data: Torque mode setpoint (Process
data IN: Torque mode setp)
-32768 ... [0] ... 32767 Nm
Mappable parameter for defining the setpoint for operating mode "MS:
Torque mode" via network.
If this parameter is to be used as standard setpoint source, the selec
tion
"Network [5]" must be set in 0x2860:003 (P201.03).
The scaling factor can be set in 0x400B:009 (P592.09).
Scaled torque setpoint = torque setpoint (0x400B:008) / 2
scaling factor
Example:
Torque setpoint (0x400B:008) = 345 [Nm]
Scaling factor (0x400C:009) = 3
Scaled torque setpoint = 345 [Nm] / 2
3
= 43.125 [Nm]
0x231F:001
(P500.01)
Module ID: Active module ID (Module ID: Active
module ID); Read only
Default setting depending on the size.
Display of the network options currently configured in the inverter.
With the help of this module ID, the keypad only shows the
communication parameters relevant to the respective network.
Note!
When switched on, the inverter checks whether the parameter settings
saved in the memory module match the inverter hardware and
firmware. In case of an incompatibility, a corresponding error message
is output. For details see chapter "Datenhandling" (section "Hardware
and firmware updates/downgrades").  113
48
No network
67 CANopen
71
80
82
84
86
87
Modbus
0x231F:002
(P500.02)
Module ID: Module ID connected (Module ID:
Module ID conn.)
Read only
For the meaning of the display see parameter
0x231F:001 (P500.01)
.  199
Display of the network option currently available in the inverter.
Note! When switched on, the inverter checks whether the parameter
settings saved in the memory module match the inverter hardware
and firmware. In case of an incompatibility, a corresponding error
message is
output. For details see chapter "Datenhandling" (section
"Hardware and
firmware updates/downgrades").

113
0x400B:009
(P592.09)
Process input data: Torque scaling (Process data IN:
Torque scaling)
-128 ... [0] ... 127
From version 02.00
Scaling factor for torque setpoint 0x400B:008 (P592.08) and actual
torque value 0x400C:007 (P593.07) via network.
With the setting 0, no scaling takes place.
Related topics
 Configuring the network  166
