12.3.1. Priority of the setpoint sources
Since only one setpoint source can be active at a time, the following priorities apply:
Flexible I/O configuration or keypad control active
0x2631:037 (P400.37) = FALSE
Network control active
0x2631:017 (P400.17) = FALSE
0x2631:037 (P400.37) = TRUE
Prio 1: Functions for setpoint change-over
The priority of the functions results from the assigned triggers (in the
order of the selection list):
Constant TRUE [1]
Digital input 1 [11]
Digital input 2 [12]
Digital input 3 [13]
5.
...
Prio 2: Set standard setpoint source
0x2860:001 (P201.01): Frequency control: Default setpoint source
0x2860:002 (P201.02): PID control: Default setpoint source
 Selection of setpoint source  93
Prio 1: Setpoint source selected via network control word
 General network settings  167
Prio 2: Set standard setpoint source
0x2860:001 (P201.01): Frequency control: Default setpoint source
0x2860:002 (P201.02): PID control: Default setpoint source
 Selection of setpoint source

93
Example of allocating priority
Parameter
Name
Setting for this example
0x2631:014 (P400.14)
Activate AI1 setpoint
Digital input 5 [15]
0x2631:016 (P400.16)
Activate keypad setpoint
Digital input 4 [14]
Digital input 4
Digital input 5
Active setpoint source
FALSE FALSE Standard setpoint source set in 0x2860:001 (P201.01)
FALSE
TRUE
Analog input 1
TRUE
FALSE
keypad
TRUE
TRUE
Keypad (since "Digital input 4" trigger is higher in the selection list than "Digital input 5" trigger)
12.3.2. Analog input setpoint source
The following functions are used to select analog input 1 or analog input 2 as setpoint
source.
Preconditions
A setpoint change-over to the respective analog input is only effected if no setpoint source
with a higher priority has been selected.
 Priority of the setpoint sources  380
Parameter
Name / value range / [default setting]
Info
0x2631:014
(P400.14)
Function list: Activate AI1 setpoint
(Function list: Setp: AI1)
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate AI1 setpoint" function.
Trigger = TRUE: analog input 1 is used as setpoint source (if the trigger
assigned has the highest setpoint priority).
Trigger = FALSE: no action / deactivate function again.
 Analog input 1

423
0
Not connected
No trigger assigned (trigger is constantly FALSE).
Parameter
Name / value range / [default setting]
Info
0x2631:015
(P400.15)
Function list: Activate AI2 setpoint
(Function list: Setp: AI2)
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate AI2 setpoint" function.
Trigger = TRUE: analog input 2 is used as setpoint source (if the trigger
assigned has the highest setpoint priority).
Trigger = FALSE: no action / deactivate function again.
 Analog input 2

427
0
Not connected
No trigger assigned (trigger is constantly FALSE).
