162 01-6203-01R3, CG Drives & Automation
Preconditions
The field controller is only effective in the motor control type "Sensorless vector control
(SLVC)".
Parameter
Name / value range / [default setting]
Info
0x29C0:001
Gain
0.00 ... [59.68]* ... 50000.00 A/Vs
* Default setting depending on the size.
Gain factor Vp of the field controller.
0x29C0:002
Reset time
1.0 ... [45.5]* ... 6000.0 ms
* Default setting depending on the size.
Reset time Tn of the field controller.
7.4.4.3. Field weakening controller
For a quick commissioning, the calculations and settings are made automatically during
the optimisation.
Preconditions
The field weakening controller is only effective in the motor control type "Sensorless
vector control (SLVC)".
Parameter
Name / value range / [default setting]
Info
0x29E0:001
Field weakening controller settings: Gain
0.000 ... [0.000]* ... 2000000.000 Vs/V
* Default setting depending on the size.
Gain factor Vp of the field weakening controller.
0x29E0:002
Field weakening controller settings: Reset time
1.0 ... [1478.3]* ... 240000.0 ms
* Default setting depending on the size.
Reset time Tn of the field weakening controller.
0x29E1
Field weakening controller Field limitation
5.00 ... [100.00] ... 100.00 %
From version 04.00
Field limitation of the field weakening controller.
7.4.4.4. Field weakening controller (advanced)
For a quick commissioning, the calculations and settings are made automatically during
the optimisation.
Preconditions
The field weakening controller is only effective in the motor control type "Sensorless
vector control (SLVC)".
Parameter
Name / value range / [default setting]
Info
0x29E2
DC-bus filter time
1.0 ... [25.0] ... 1000.0 ms
Filter time for the current DC-bus voltage.
0x29E3
Motor voltage filter time
1.0 ... [25.0] ... 1000.0 ms
Filter time for the current motor voltage.
0x29E4
(P354.00)
Voltage reserve range
(Voltage reserve)
1 ... [5] ... 20 %
Voltage reserve range at the transition point to the field weakening.
Only relevant if 0x2C00 (P300.00) is set = "Servo control (SC ASM) [2]".
