Emotron VS10 User Manual

478 01-6203-01R3, CG Drives & Automation
14.2. Error codes
The following table contains all error codes of the inverter in ascending order.
Error code
Info
Error type
Adjustable in
dec
hex
Keypad display
Error message
8784
0x2250
PU over current
CiA: Continuous over current (internal)
Fault
-
This message contains three errors:
Continuous overcurrent on the inverter/motor side.
Overcurrent at the brake chopper (brake transistor).
DC bus relay has not been closed due to a malfunction.
Notes:
Serious error: The inverter is inhibited immediately. The motor becomes torqueless
(coasts).
The error can only be reset after a blocking time of 5 s.
8992
0x2320
Earth leak
CiA: Short circuit/earth leakage (internal)
Fault
-
Notes:
Serious error: The inverter is inhibited immediately. The motor becomes torqueless
(coasts).
The error can only be reset after a blocking time of 5 s.
9024 0x2340 Motor shorted CiA: Short circuit (device internal) Fault -
Notes:
Serious error: The inverter is inhibited immediately. The motor becomes torqueless
(coasts).
The error can only be reset after a blocking time of 5 s.
9040
0x2350
Motor i2t OL
CiA: i²*t overload (thermal state)
Fault
-
Notes:
The error can only be reset after a blocking time of 5 s.
9090
0x2382
Ixt error
I*t error
Fault
0x2D40:005
(P135.05)
The device utilisation has exceeded the warning threshold set in 0x2D40:002 (default
setting: 95 %).
 Device overload monitoring (i*t)  82
Notes:
Serious error: The inverter is inhibited immediately. The motor becomes torqueless
(coasts).
The error can only be reset after a blocking time of 3 s.
9091
0x2383
Ixt warning
I*t warning
Warning
-
The device utilisation has exceeded the permanent error threshold of 100 %.
 Device overload monitoring (i*t)  82
Notes:
Logging only (Error history buffer/Logbook)
9095
0x2387
Clamp timeout
Imax: Clamp responded too often
Fault
-
"Clamp" = short-time inhibit of the inverter in V/f operation when the current limit shown
in 0x2DDF:002 is reached.
Notes:
Serious error: The inverter is inhibited immediately. The motor becomes torqueless
(coasts).
9096 0x2388 SLPSM stall det. SLPSM stall detection active Trouble -
Stalling protection for the sensorless control for synchronous motors (SLPSM) is active.
Possible cause: Overload of the motor.
 Stall monitoring  120
Notes:
Serious fault: The inverter is inhibited immediately. The motor becomes torqueless
(coasts).
12576
0x3120
Mains Phase fail
Mains phase fault
Fault
-
Notes:
Serious error: The inverter is inhibited immediately. The motor becomes torqueless
(coasts).
