Emotron VS10 - Favorites Parameter List (Default Setting)

10.8.2. Favorites parameter list (default setting)
In the default setting, the most common parameters for the solution of typical
applications are defined as "Favorites":
No.
Display code
Name
Default setting
Setting range
Info
1
P100.00
Output frequency
x.x Hz
(Read only)
0x2DDD (P100.00)
2
P103.00
Current actual
x.x %
(Read only)
0x6078 (P103.00)
3 P106.00 Motor voltage x VAC (Read only) 0x2D89 (P106.00)
4
P150.00
Error code
-
(Read only)
0x603F (P150.00)
5
P200.00
Control select.
0
0 ... 1
0x2824 (P200.00)
6
P201.01
Freq. setp. src.
2
0 ... 255
0x2860:001 (P201.01)
7
P203.01
Start method
0
0 ... 255
0x2838:001 (P203.01)
8 P203.03 Stop method 1 0 ... 255 0x2838:003 (P203.03)
9
P208.01
Mains voltage
0
0 ... 255
0x2540:001 (P208.01)
10
P210.00
Min. frequency
0.0 Hz
0.0 ... 599.0 Hz
0x2915 (P210.00)
11
P211.00
Max. frequency
50.0 Hz* | 60.0 Hz**
0.0 ... 599.0 Hz
0x2916 (P211.00)
12
P220.00
Accelerat.time 1
5.0 s
0.0 ... 3600.0 s
0x2917 (P220.00)
13 P221.00 Decelerat.time 1 5.0 s 0.0 ... 3600.0 s 0x2918 (P221.00)
14
P300.00
Motor ctrl mode
6
1 ... 7
0x2C00 (P300.00)
15
P302.00
V/f charac.shape
0
0 ... 3
0x2B00 (P302.00)
16
P303.01
Base voltage
230 V
0 ... 5000 V
0x2B01:001 (P303.01)
17
P303.02
Base frequency
50 Hz* | 60 Hz**
0 ... 1500 Hz
0x2B01:002 (P303.02)
18 P304.00 Limit. rotation 1 0 ... 255 0x283A (P304.00)
19
P305.00
Switching freq.
0
1 ... 33
0x2939 (P305.00)
20
P308.01
Max.load.for 60s
150 %
30 ... 200 %
0x2D4B:001 (P308.01)
21
P316.01
Fixed V/f boost
2.5 %
0.0 ... 20.0 %
0x2B12:001 (P316.01)
22
P324.00
Max current
200.0 %
0.0 ... 3000.0 %
0x6073 (P324.00)
23 P400.01 Enable inverter 1 0 ... 255 0x2631:001 (P400.01)
24
P400.02
Run
Digital input 1 [11]
Selection list
0x2631:002 (P400.02)
25
P400.03
Quick stop
Not connected [0]
Selection list
0x2631:003 (P400.03)
26
P400.04
Reset fault
Digital input 2 [12]
Selection list
0x2631:004 (P400.04)
27
P400.05
DC braking
Not connected [0]
Selection list
0x2631:005 (P400.05)
28 P400.06 Start forward Not connected [0] Selection list 0x2631:006 (P400.06)
29
P400.07
Start reverse
Not connected [0]
Selection list
0x2631:007 (P400.07)
30
P400.08
Run forward
Not connected [0]
Selection list
0x2631:008 (P400.08)
31
P400.09
Run reverse
Not connected [0]
Selection list
0x2631:009 (P400.09)
32
P400.13
Invert rotation
Digital input 3 [13]
Selection list
0x2631:013 (P400.13)
33 P400.18 Setp: Preset b0 Digital input 4 [14] Selection list 0x2631:018 (P400.18)
34
P400.19
Setp: Preset b1
Digital input 5 [15]
Selection list
0x2631:019 (P400.19)
35
P400.20
Setp: Preset b2
Not connected [0]
Selection list
0x2631:020 (P400.20)
36
P420.01
Relay function
51
0 ... 255
0x2634:001 (P420.01)
37
P420.02
DO1 function
Release brake [115]
Selection list
0x2634:002 (P420.02)
38 P430.01 AI1 input range 0 0 ... 255 0x2636:001 (P430.01)
39
P430.02
AI1 freq @ min
0.0 Hz
-1000.0 ... 1000.0 Hz
0x2636:002 (P430.02)
40
P430.03
AI1 freq @ max
50.0 Hz* | 60.0 Hz**
-1000.0 ... 1000.0 Hz
0x2636:003 (P430.03)
41
P440.01
AO1 outp. range
1
0 ... 5
0x2639:001 (P440.01)
42
P440.02
AO1 function
1
0 ... 255
0x2639:002 (P440.02)
43 P440.03 AO1 min. signal 0 -2147483648 ... 2147483647 0x2639:003 (P440.03)
44
P440.04
AO1 max. signal
1000
-2147483648 ... 2147483647
0x2639:004 (P440.04)
