Emotron VS10 User Manual

460 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x2639:001
(P440.01)
Analog output 1: Output range
(Analog output 1: AO1 outp. range)
Definition of the output range.
0
Inhibited
1
0 ... 10 VDC
2
0 ... 5 VDC
3
2 ... 10 VDC
4
4 ... 20 mA
5
0 ... 20 mA
0x2639:002
(P440.02)
Analog output 1: Function
(Analog output 1: AO1 function)
Selection of the signal to be shown at analog output 1.
0
Not active
No output signal.
1
Output frequency
Actual output frequency (resolution: 0.1 Hz).
2
Frequency setpoint
Actual frequency setpoint (resolution: 0.1 Hz).
3
Analog input 1
Input signal of analog input 1 (resolution: 0.1 %).
4
Analog input 2
Input signal of analog input 2 (resolution: 0.1 %).
5
Motor current
Actual motor current (resolution: 0.1 A).
6
Output power
Actual output power (resolution: 0.001 kW).
7
Torque actual value
(from version 03.00)
Torque actual value (resolution: 0.1 %).
100 % ≡ permissible maximum torque 0x6072 (P326.00)
10
Sequencer controlled
(from version 03.00)
Voltage value which has been set for the currently executed sequencer
segment (resolution: 0.01 V).
 Sequencer

327
20
NetWordIN3
Actual value of the NetWordIN3 data word (resolution: 0.1 %).
 Further process data  191
21
NetWordIN4
Actual value of the NetWordIN4 data word (resolution: 0.1 %).
 Further process data

191
0x2639:003
(P440.03)
Analog output 1: Min. signal
(Analog output 1: AO1 min. signal)
-2147483648 ... [0] ... 2147483647
Definition of the signal value that corresponds to the minimum value at
analog output 1.
Example: configuration of analog output 1 as a 4 ... 20 mA current loop:
output current 4 mA ≡ 0x2639:003
0x2639:004
(P440.04)
Analog output 1: Max. signal
(Analog output 1: AO1 max. signal)
-2147483648 ... [1000] ... 2147483647
Definition of the signal value that corresponds to the maximum value at
analog output 1.
Example: configuration of analog output 1 as a 4 ... 20 mA current loop:
output current 20 mA ≡ 0x2639:004
0x4008:003
(P590.03)
Process input words: NetWordIN3
(NetWordINx: NetWordIN3)
0.0 ... [0.0] ... 100.0 %
Mappable data word for optional control of an analog output via net-
work.
Assignment of the analog output:
•
Analog output 1: 0x2639:002 (P440.02) = "NetWordIN3 [20]"
0x4008:004
(P590.04)
Process input words: NetWordIN4
(NetWordINx: NetWordIN4)
0.0 ... [0.0] ... 100.0 %
Mappable data word for optional control of an analog output via net-
work.
Assignment of the analog output:
•
Analog output 1: 0x2639:002 (P440.02) = "NetWordIN4 [21]"
