Emotron VS10 - Basic Inverter Settings

4.3.2. Basic inverter settings
Check the following basic settings of the inverter and adapt them, if required.
Parameter
Name / value range / [default setting]
Info
0x2540:001
(P208.01)
Mains settings: Rated mains voltage
(Mains settings: Mains voltage)
•
Setting can only be changed if the inverter is
inhibi
ted.
Selection of the mains voltage for actuating the inverter.
0
230 Veff
1
400 Veff
2 480 Veff
0x2838:001
(P203.01)
Start/stop configuration: Start method
(Start/stop confg: Start method)
•
Setting can only be changed if the inverter is
inhibi
ted.
Behaviour after start command.
0
Normal
After start command, the standard ramps are active.
• Acceleration time 1 can be set in 0x2917 (P220.00).
•
Deceleration time 1 can be set in 0x2918 (P221.00).
1
DC braking
After start command, the "DC braking" function is active for the time set
in 0x2B84:002 (P704.02).
 DC braking

262
2
Flying restart circuit
After the start command, the flying restart circuit is active.
The flying restart function makes it possible to restart a coasting motor
during operation without speed feedback. Synchronicity between the
inverter and motor is coordinated so that the transition to the rotating
motor is effected without jerk at the time of connection.
 Flying restart circuit

311
0x2838:002
(P203.02)
Start/stop configuration: Start at power-up
(Start/stop confg: Start at powerup)
Starting performance after switching on the mains voltage.
0
Off
No automatic start after switching on mains voltage. In addition to the
inverter enable, a renewed start command is always required to start the
motor.
1
On
Automatic start of the motor after switching on the mains voltage if the
inverter is enabled and a start command exists.
0x2838:003
(P203.03)
Start/stop configuration: Stop method
(Start/stop confg: Stop method)
Behaviour after the "Stop" command.
0
Coasting
The motor becomes torqueless (coasts down to standstill).
1
Standard ramp
The motor is brought to a standstill with deceleration time 1 (or
deceleration time 2, if activated).
• Deceleration time 1 can be set in 0x2918 (P221.00).
• Deceleration time 2 can be set in 0x291A (P223.00).
 Frequency limits and ramp times

100
2 Quick stop ramp The motor is brought to a standstill with the deceleration time set for
the "Quick stop" function.
• Deceleration time for quick stop can be set in 0x291C (P225.00).
•
The "quick stop" function can also be activated manually, for instance
via a digital input.
 Quick stop  103
0x283A
(P304.00)
Limitation of rotation
(Limit. rotation)
Optional restriction of the rotating direction.
0
Only clockwise (CW)
The motor can only be rotated clockwise (CW). The transfer of negative
frequency and PID setpoints to the motor control is prevented.
•
This function takes effect after the "Invert rotation" function
(0x2631:013 (P400.13)).
•
Since this function only prevents negative setpoints, counter-
clock
wise rotation (CCW) is possible if the motor has been wired
for this rotating direction.
1
Both rotation directions
Both directions of motor rotation are enabled.
